Cross Site Request Forgery (CSRF)

@Configuration
@EnableWebSecurity
public class SecurityConfig {

	@Bean
	public SecurityFilterChain securityFilterChain(HttpSecurity http) throws Exception {
		http
			// ...
			.csrf((csrf) -> csrf
				.csrfTokenRepository(CookieCsrfTokenRepository.withHttpOnlyFalse())   (1)
				.csrfTokenRequestHandler(new SpaCsrfTokenRequestHandler())            (2)
			)
			.addFilterAfter(new CsrfCookieFilter(), BasicAuthenticationFilter.class); (3)
		return http.build();
	}
}

final class SpaCsrfTokenRequestHandler extends CsrfTokenRequestAttributeHandler {
	private final CsrfTokenRequestHandler delegate = new XorCsrfTokenRequestAttributeHandler();

	@Override
	public void handle(HttpServletRequest request, HttpServletResponse response, Supplier<CsrfToken> csrfToken) {
		/*
		 * Always use XorCsrfTokenRequestAttributeHandler to provide BREACH protection of
		 * the CsrfToken when it is rendered in the response body.
		 */
		this.delegate.handle(request, response, csrfToken);
	}

	@Override
	public String resolveCsrfTokenValue(HttpServletRequest request, CsrfToken csrfToken) {
		/*
		 * If the request contains a request header, use CsrfTokenRequestAttributeHandler
		 * to resolve the CsrfToken. This applies when a single-page application includes
		 * the header value automatically, which was obtained via a cookie containing the
		 * raw CsrfToken.
		 */
		if (StringUtils.hasText(request.getHeader(csrfToken.getHeaderName()))) {
			return super.resolveCsrfTokenValue(request, csrfToken);
		}
		/*
		 * In all other cases (e.g. if the request contains a request parameter), use
		 * XorCsrfTokenRequestAttributeHandler to resolve the CsrfToken. This applies
		 * when a server-side rendered form includes the _csrf request parameter as a
		 * hidden input.
		 */
		return this.delegate.resolveCsrfTokenValue(request, csrfToken);
	}
}

final class CsrfCookieFilter extends OncePerRequestFilter {

	@Override
	protected void doFilterInternal(HttpServletRequest request, HttpServletResponse response, FilterChain filterChain)
			throws ServletException, IOException {
		CsrfToken csrfToken = (CsrfToken) request.getAttribute("_csrf");
		// Render the token value to a cookie by causing the deferred token to be loaded
		csrfToken.getToken();

		filterChain.doFilter(request, response);
	}
}

import org.springframework.security.config.annotation.web.invoke

@Configuration
@EnableWebSecurity
class SecurityConfig {

    @Bean
    open fun securityFilterChain(http: HttpSecurity): SecurityFilterChain {
        http {
            // ...
            csrf {
                csrfTokenRepository = CookieCsrfTokenRepository.withHttpOnlyFalse()    (1)
                csrfTokenRequestHandler = SpaCsrfTokenRequestHandler()                 (2)
            }
        }
        http.addFilterAfter(CsrfCookieFilter(), BasicAuthenticationFilter::class.java) (3)
        return http.build()
    }
}

class SpaCsrfTokenRequestHandler : CsrfTokenRequestAttributeHandler() {
    private val delegate: CsrfTokenRequestHandler = XorCsrfTokenRequestAttributeHandler()

    override fun handle(request: HttpServletRequest, response: HttpServletResponse, csrfToken: Supplier<CsrfToken>) {
        /*
         * Always use XorCsrfTokenRequestAttributeHandler to provide BREACH protection of
         * the CsrfToken when it is rendered in the response body.
         */
        delegate.handle(request, response, csrfToken)
    }

    override fun resolveCsrfTokenValue(request: HttpServletRequest, csrfToken: CsrfToken): String {
        /*
         * If the request contains a request header, use CsrfTokenRequestAttributeHandler
         * to resolve the CsrfToken. This applies when a single-page application includes
         * the header value automatically, which was obtained via a cookie containing the
         * raw CsrfToken.
         */
        return if (StringUtils.hasText(request.getHeader(csrfToken.headerName))) {
            super.resolveCsrfTokenValue(request, csrfToken)
        } else {
            /*
             * In all other cases (e.g. if the request contains a request parameter), use
             * XorCsrfTokenRequestAttributeHandler to resolve the CsrfToken. This applies
             * when a server-side rendered form includes the _csrf request parameter as a
             * hidden input.
             */
            delegate.resolveCsrfTokenValue(request, csrfToken)
        }
    }
}

class CsrfCookieFilter : OncePerRequestFilter() {

    @Throws(ServletException::class, IOException::class)
    override fun doFilterInternal(request: HttpServletRequest, response: HttpServletResponse, filterChain: FilterChain) {
        val csrfToken = request.getAttribute("_csrf") as CsrfToken
        // Render the token value to a cookie by causing the deferred token to be loaded
        csrfToken.token
        filterChain.doFilter(request, response)
    }
}

<http>
	<!-- ... -->
	<csrf
		token-repository-ref="tokenRepository"                        1
		request-handler-ref="requestHandler"/>                        2
	<custom-filter ref="csrfCookieFilter" after="BASIC_AUTH_FILTER"/> 3
</http>
<b:bean id="tokenRepository"
	class="org.springframework.security.web.csrf.CookieCsrfTokenRepository"
	p:cookieHttpOnly="false"/>
<b:bean id="requestHandler"
	class="example.SpaCsrfTokenRequestHandler"/>
<b:bean id="csrfCookieFilter"
	class="example.CsrfCookieFilter"/>

@ControllerAdvice
public class CsrfControllerAdvice {

	@ModelAttribute
	public void getCsrfToken(HttpServletResponse response, CsrfToken csrfToken) {
		response.setHeader(csrfToken.getHeaderName(), csrfToken.getToken());
	}

}

@ControllerAdvice
class CsrfControllerAdvice {

	@ModelAttribute
	fun getCsrfToken(response: HttpServletResponse, csrfToken: CsrfToken) {
		response.setHeader(csrfToken.headerName, csrfToken.token)
	}

}

public class SecurityApplicationInitializer extends AbstractSecurityWebApplicationInitializer {

	@Override
	protected void beforeSpringSecurityFilterChain(ServletContext servletContext) {
		insertFilters(servletContext, new MultipartFilter());
	}
}

class SecurityApplicationInitializer : AbstractSecurityWebApplicationInitializer() {
    override fun beforeSpringSecurityFilterChain(servletContext: ServletContext?) {
        insertFilters(servletContext, MultipartFilter())
    }
}

<filter>
	<filter-name>MultipartFilter</filter-name>
	<filter-class>org.springframework.web.multipart.support.MultipartFilter</filter-class>
</filter>
<filter>
	<filter-name>springSecurityFilterChain</filter-name>
	<filter-class>org.springframework.web.filter.DelegatingFilterProxy</filter-class>
</filter>
<filter-mapping>
	<filter-name>MultipartFilter</filter-name>
	<url-pattern>/*</url-pattern>
</filter-mapping>
<filter-mapping>
	<filter-name>springSecurityFilterChain</filter-name>
	<url-pattern>/*</url-pattern>
</filter-mapping>
